石油烃在非均质包气带中的吸附作用及迁移规律

薛镇坤 左锐 王金生 陈敏华 孟利 靳超

薛镇坤, 左锐, 王金生, 陈敏华, 孟利, 靳超. 石油烃在非均质包气带中的吸附作用及迁移规律[J]. 环境科学研究, 2020, 33(4): 1028-1036. doi: 10.13198/j.issn.1001-6929.2019.09.05
引用本文: 薛镇坤, 左锐, 王金生, 陈敏华, 孟利, 靳超. 石油烃在非均质包气带中的吸附作用及迁移规律[J]. 环境科学研究, 2020, 33(4): 1028-1036. doi: 10.13198/j.issn.1001-6929.2019.09.05
XUE Zhenkun, ZUO Rui, WANG Jinsheng, CHEN Minhua, MENG Li, JIN Chao. Migration of Petroleum Pollutants in Strong Heterogeneous Vadose Zones[J]. Research of Environmental Sciences, 2020, 33(4): 1028-1036. doi: 10.13198/j.issn.1001-6929.2019.09.05
Citation: XUE Zhenkun, ZUO Rui, WANG Jinsheng, CHEN Minhua, MENG Li, JIN Chao. Migration of Petroleum Pollutants in Strong Heterogeneous Vadose Zones[J]. Research of Environmental Sciences, 2020, 33(4): 1028-1036. doi: 10.13198/j.issn.1001-6929.2019.09.05

石油烃在非均质包气带中的吸附作用及迁移规律

doi: 10.13198/j.issn.1001-6929.2019.09.05
基金项目:

国家自然科学基金项目 41877181

国家自然科学基金项目 41831283

详细信息
    作者简介:

    薛镇坤(1995-), 男, 江苏南通人, xzkbjsf@163.com

    通讯作者:

    左锐(1981-), 男, 安徽枞阳人, 教授级高级工程师, 博士, 博导, 主要从事地下水污染与控制研究, zr@bnu.edu.cn

  • 中图分类号: X53;X172

Migration of Petroleum Pollutants in Strong Heterogeneous Vadose Zones

Funds:

National Natural Science Foundation of China 41877181

National Natural Science Foundation of China 41831283

  • 摘要: 为深入分析强非均质性污染场地中石油烃的运移规律,探究石油烃类污染物在场地中的吸附、迁移及其影响因素,选取潮白河上游为典型研究区,受冲洪积扇条件控制,区域内包气带非均质性强,地下水埋深较大.采集污染场地包气带介质样品,分别装填原状土(0~20 mm)、细颗粒(< 2 mm)和粗颗粒(>4 mm)3种介质迁移柱,通过土柱淋滤试验表征石油烃在典型介质中的迁移特性;通过静态吸附试验和微生物降解试验识别石油烃迁移过程的关键影响因素,揭示多要素作用条件下的石油烃迁移规律.结果表明:原状土、细颗粒和粗颗粒这3种介质迁移柱出水中石油烃浓度均呈先下降、后波动上升、最终趋于稳定的趋势.3种介质对石油烃的吸附过程均呈现快吸附和慢吸附两个阶段,快吸附阶段发生在试验0~15 h内,完成了吸附的70%~80%;慢吸附阶段持续时间较长,吸附总量缓慢增加.固液比、温度和pH等要素对3种介质石油烃吸附性能的影响相对较小.微生物降解是慢吸附阶段石油烃浓度呈波动上升的主要原因,且在整个石油烃垂向迁移过程中,吸附作用对石油烃去除的贡献率为80%,微生物降解的贡献率为20%.研究显示,相对于微生物作用而言,强非均匀介质在石油烃类污染场地的污染物吸附和迁移过程中起关键控制作用.



  • 图  1  研究区实际地层剖面

    Figure  1.  Stratigraphic image of the study area

    图  2  不同介质各时段出水石油烃浓度与去除率

    Figure  2.  Effluent concentration and Removal rate of petroleum hydrocarbons in different media

    图  3  柱Ⅰ中石油烃浓度变化规律

    Figure  3.  Variation law of petroleum hydrocarbon concentration in column Ⅰ

    图  5  柱Ⅲ中石油烃浓度变化规律

    Figure  5.  Variation law of petroleum hydrocarbon concentration in column Ⅲ

    图  4  柱Ⅱ中石油烃浓度变化规律

    Figure  4.  Variation law of petroleum hydrocarbon concentration in column Ⅱ

    图  6  3种典型介质吸附动力学曲线

    Figure  6.  Adsorption kinetics curve of three typical media

    图  7  3种典型介质的热力学吸附曲线

    注:温度为15 ℃.

    Figure  7.  Thermodynamic adsorption curve of three typical media

    图  8  固液比、温度和pH对吸附性的影响

    Figure  8.  Effect of solid-to-liquid ratio, temperature and pH on adsorption

    图  9  有无灭菌条件下石油烃穿透曲线

    Figure  9.  Breakthrough curve of petroleum hydrocarbons in both cases

    表  1  淋滤试验土柱及填充介质参数

    Table  1.   Parameter list of soil column and packing medium for leaching experiment

    土柱名称 介质类型 粒度/mm 含量/% 备注
    细颗粒 < 2 100 原状土过分选筛,介质粒径小于2 mm
    < 2 35 过大孔筛,剔除植物根系和难以填充的大颗粒砾石
    原状土 2~20 45
    20 10
    粗颗粒 4~20 33.3 经筛选,取4~20 mm介质与>20 mm介质按1:2比例混合后填充
    >20 66.7
    下载: 导出CSV

    表  2  吸附要素试验条件

    Table  2.   Settings of adsorption experiment conditions

    影响因素 溶液体积/mL 初始质量浓度/(mg/L) 振荡温度/℃ 吸附介质质量/g 振荡时间/h pH
    固液比 40 12.712 15 0.2、0.4、1.0、2.0、4.0 24 7
    温度 40 12.712 5、15、25、35、45 1.0 24 7
    pH 40 12.712 15 1.0 24 3、5、7、9、11
    下载: 导出CSV

    表  3  微生物降解试验用柱及填充介质参数

    Table  3.   Parameter list of soil column and packing medium for microbial degradation experiment

    土柱编号 柱长/cm 内径/cm 厚度 处理方法 迁移作用
    柱A 25 6 8 mm有机玻璃 灭菌(加入HgCl2) 吸附
    柱B 25 6 8 mm有机玻璃 不灭菌 吸附-微生物降解
    下载: 导出CSV

    表  4  热力学试验数据拟合参数

    Table  4.   Thermodynamic experimental data fitting parameters

    介质 Langmuir等温吸附模型 Freundlich等温吸附模型
    KL/(L/g) Cm/(mg/L) R2 Kf 1/n R2
    细颗粒 0.026 02 1.427 44 0.979 99 0.038 36 0.883 68 0.973 87
    原状土 0.041 01 0.767 64 0.992 29 0.034 14 0.813 01 0.986 78
    粗颗粒 0.030 16 0.66 120 0.983 93 0.021 27 0.855 26 0.979 38
    注:KL为Langmuir等温吸附常数,L/g;Kf为Freundlich等温吸附常数;C m为吸附平衡时溶液中的石油烃浓度,mg/L;1/n为Freundlich常数;R为相关系数.
    下载: 导出CSV
  • [1] ZHANG Q, WANG G, SUGIURA N, et al.Distribution of petroleum hydrocarbons in soils and the underlying unsaturated subsurface at an abandoned petrochemical site, North China[J].Hydrological Processes, 2014, 28(4):2185-2191. doi: 10.1002/hyp.9770
    [2] TOTSCHE K U, RENNERT T, GERZABEK M H, et al.Biogeochemical interfaces in soil:the interdisciplinary challenge for soil science[J].Journal of Plant Nutrition and Soil Science, 2010, 173(1):88-99. doi: 10.1002/jpln.200900105
    [3] SI Z Y, XI W, LIANG Z, et al.Crude oil treatment leads to shift of bacterial communities in soils from the deep active layer and upper permafrost along the China-Russia crude oil pipeline route[J].Plos One, 2014, 9(5):e96552. doi: 10.1371/journal.pone.0096552
    [4] 杨明星, 杨悦锁, 杜新强, 等.石油污染地下水有机污染组分特征及其环境指示效应[J].中国环境科学, 2013, 33(6):1025-1032. doi: 10.3969/j.issn.1000-6923.2013.06.010

    YANG Mingxing, YANG Yuesuo, DU Xinqiang, et al.Organic fraction and environmental implication of petroleum contaminated groundwater[J].China Environmental Science, 2013, 33(6):1025-1032. doi: 10.3969/j.issn.1000-6923.2013.06.010
    [5] PU X, CUTRIGHT T J.Sorption-desorption behavior of PCP on soil organic matter and clay minerals[J].Chemosphere, 2006, 64(6):972-983. doi: 10.1016/j.chemosphere.2006.01.017
    [6] MECKENSTOCK R U, ELSNER M, GRIEBLER C, et al.Biodegradation:updating the concepts of control for microbial cleanup in contaminated aquifers[J].Environmental Science & Technology, 2015, 49(12):7073-7081. http://d.old.wanfangdata.com.cn/NSTLQK/NSTL_QKJJ0222173658/
    [7] WIEDEMEIER T H, SWANSON M A, WILSON J T, et al.Approximation of biodegradation rate constants for monoaromatic hydrocarbons (BTEX) in ground water[J].Groundwater Monitoring & Remediation, 2010, 16(3):186-194. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=10.1111/j.1745-6592.1996.tb00149.x
    [8] 刘晓艳, 纪学雁, 李兴伟, 等.石油类污染物在土壤中迁移的实验研究进展[J].土壤, 2005, 37(5):482-486. doi: 10.3321/j.issn:0253-9829.2005.05.003

    LIU Xiaoyan, JI Xueyan, LI Xingwei, et al.Migration of petroleum-series contaminants in the soil[J].Soils, 2005, 37(5):482-486. doi: 10.3321/j.issn:0253-9829.2005.05.003
    [9] LARSEN T, KJELDSEN P, CHRISTENSEN T H.Sorption of hydrophobic hydrocarbons on three aquifer materials in a flow through system[J].Chemosphere, 1992, 24(4):439-451. doi: 10.1016/0045-6535(92)90419-R
    [10] LEAHY J G, COLWELL R R.Microbial degradation of hydrocarbons in the environment[J].Microbiological Reviews, 1990, 54(3):305-315. doi: 10.1128/MMBR.54.3.305-315.1990
    [11] MIHELCIC J R, LUTHY R G.Sorption and microbial degradation of naphalene in soil-water suspensions under denitrification conditions[J].Environmental Science & Technology, 1991, 25(1):169-177.
    [12] FAUST C R.Transport of immiscible fluids within and below the unsaturated zone:a numerical model[J].Water Resources Research, 1985, 21(4):587-596. doi: 10.1029/WR021i004p00587
    [13] ABRIOLA L M.Multiphase migration of organic compounds in a porous medium:a mathematical model[M].Berlin, Germany:Springer Science & Business Media, 2013.
    [14] 潘峰, 陈丽华, 付素静, 等.石油类污染物在陇东黄土塬区土壤中迁移的模拟试验研究[J].环境科学学报, 2012, 32(2):410-418. http://d.old.wanfangdata.com.cn/Periodical/hjkxxb201202019

    PAN Feng, CHEN Lihua, FU Sujing, et al.A study on the transport performance of the petroleum contaminants in soil of the Longdong Loess Plateau[J].Acta Scientiae Circumstantiae, 2012, 32(2):410-418. http://d.old.wanfangdata.com.cn/Periodical/hjkxxb201202019
    [15] 孔露露, 周启星.新制备生物炭的特性表征及其对石油烃污染土壤的吸附效果[J].环境工程学报, 2015, 9(5):2462-2468. http://d.old.wanfangdata.com.cn/Periodical/hjwrzljsysb201505070

    KONG Lulu, ZHOU Qixing.Characterization of new-prepared biochars and their adsorption effectiveness on petroleum hydrocarbon contaminated soil[J].Chinese Journal Environment Engineering, 2015, 9(5):2462-2468. http://d.old.wanfangdata.com.cn/Periodical/hjwrzljsysb201505070
    [16] 鲍艳宇, 周启星, 鲍艳姣, 等.3种四环素类抗生素在石油污染土壤上的吸附解吸[J].中国环境科学, 2012, 32(7):1257-1262. doi: 10.3969/j.issn.1000-6923.2012.07.017

    BAO Yanyu, ZHOU Qixing, BAO Jiaoyan, et al.Adsorption and desorption of three tetracycline antibiotics in petroleum-contaminated soils[J].China Environmental Science, 2012, 32(7):1257-1262. doi: 10.3969/j.issn.1000-6923.2012.07.017
    [17] 陈虹, 陈硕, 全燮, 等.土壤-水体系中固/液比对溶解性石油烃吸附的影响[J].环境科学, 2007, 28(6):1295-1299. doi: 10.3321/j.issn:0250-3301.2007.06.023

    CHEN Hong, CHEN Shuo, QUAN Xie, et al.Effects of solid-to-solution ratio on sorption of dissolved petroleum hydrocarbons to soils[J].Environmental Science, 2007, 28(6):1295-1299. doi: 10.3321/j.issn:0250-3301.2007.06.023
    [18] 张博.石油污染物在土壤中迁移规律及修复技术研究[D].大庆: 东北石油大学, 2017.
    [19] 郭敏丽, 王金生, 杨志兵, 等.非正规垃圾填埋场包气带介质的污染物阻滞能力研究[J].环境污染与防治, 2012, 34(1):24-26. doi: 10.3969/j.issn.1001-3865.2012.01.006

    GUO Minli, WANG Jinsheng, YANG Zhibing, et al.Study on the pollutant retarded capability of different media in aerated zone of informal landfill[J].Environmental Pollution & Control, 2012, 34(1):24-26. doi: 10.3969/j.issn.1001-3865.2012.01.006
    [20] 肖德娟.水中石油类物质测定的红外分光光度法[J].科技资讯, 2013(8):175-175. doi: 10.3969/j.issn.1672-3791.2013.08.125
    [21] BEILEN J B V, WUBBOLTS M G, WITHOLT B.Genetics of alkane oxidation by Pseudomonas oleovorans[J].Biodegradation, 1994, 5(3/4):161-174.
    [22] ZHANG Z, GAI L, HOU Z, et al.Characterization and biotechnological potential of petroleum-degrading bacteria isolated from oil-contaminated soils[J].Bioresource Technology, 2010, 101(21):8452-8456. doi: 10.1016/j.biortech.2010.05.060
    [23] VARJANI S J, UPASANI V N.A new look on factors affecting microbial degradation of petroleum hydrocarbon pollutants[J].International Biodeterioration & Biodegradation, 2017, 120:71-83. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=3e46427bd918dd16924fdbb978117c1f
    [24] 史红星, 黄廷林.黄土地区土壤对石油类污染物吸附特性的实验研究[J].环境科学与技术, 2002, 25(3): 10-12.

    SHI Hongxing, HUANG Tinling.Characteristics of adsorption of mineral oils on loess[J].Environmental Science & Technology (China), 25(3): 10-12.
    [25] REEVES W R, MCDONALD T J, CIZMAS L, et al.Partitioning and desorption behavior of polycyclic aromatic hydrocarbons from disparate sources[J].Science of the Total Environment, 2004, 332(1/2/3):183-192. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=a89afc1dfa9f8fba52329d652a583736
    [26] 吴俊文, 郑西来, 李玲玲, 等.沙土对可溶性油的吸附作用及其影响因素研究[J].环境科学, 2006, 27(10):2019-2023. doi: 10.3321/j.issn:0250-3301.2006.10.017

    WU Junwen, ZHENG Xilai, LI Lingling, et al.Adsorption of aqueous oil on sands and its studies of effective factors[J].Environmental Science, 2006, 27(10):2019-2023. doi: 10.3321/j.issn:0250-3301.2006.10.017
    [27] TOMLINSON D W, RIVETT M O, WEALTHALL G P, et al.Understanding complex LNAPL sites:illustrated handbook of LNAPL transport and fate in the subsurface[J].Journal of Environmental Management, 2017, 204:48-756. http://cn.bing.com/academic/profile?id=f659a6c566f621d7e85f2219e0fb894e&encoded=0&v=paper_preview&mkt=zh-cn
    [28] 李玉瑛.土-水系统石油污染物挥发和生物降解过程研究[D].青岛: 中国海洋大学, 2005. http://cdmd.cnki.com.cn/Article/CDMD-10423-2005140471.htm
    [29] YU K S H, WONG A H Y, YAU K W Y, et al.Natural attenuation, biostimulation and bioaugmentation on biodegradation of polycyclic aromatic hydrocarbons(PAHs)in mangrove sediments[J].Marine Pollution Bulletin, 2005, 51(8/9/10/11/12):1071-1077. http://cn.bing.com/academic/profile?id=b81d3b918ec2e2d1b7493c37cd0a52e3&encoded=0&v=paper_preview&mkt=zh-cn
    [30] 赵硕伟, 沈嘉澍, 沈标.复合菌群的构建及其对石油污染土壤修复的研究[J].农业环境科学学报, 2011, 30(8):1567-1572. http://www.cnki.com.cn/Article/CJFDTotal-NHBH201108017.htm

    ZHAO Shuowei, SHEN Jiashu, SHEN Biao.Construction of multiple bacterial consortium and its application in bioremediation of petroleum-contaminated soil[J].Journal of Agro-Environment Science, 2011, 30(8):1567-1572. http://www.cnki.com.cn/Article/CJFDTotal-NHBH201108017.htm
