焙烧再生废旧臭氧催化剂处理石化废水生化出水

秦志凯; 付丽亚; 李敏; 吴昌永

doi:10.13198/j.issn.1001-6929.2022.11.13

焙烧再生废旧臭氧催化剂处理石化废水生化出水

doi: 10.13198/j.issn.1001-6929.2022.11.13

秦志凯^{1, 2,},
付丽亚^{1, 2},
李敏^{1, 2},
吴昌永^{1, 2, ,}

1.
中国环境科学研究院环境污染控制工程技术研究中心，北京　100012
2.
中国环境科学研究院，环境基准与风险评估国家重点实验室，北京　100012

基金项目: 国家重点研发计划项目(No.2020YFC1806302-03)

详细信息

作者简介:
秦志凯（1999-），男，河南清丰县人，1123698149@qq.com

通讯作者:
吴昌永(1980-)，男，山东兰陵人，研究员，博士，博导，主要从事水污染控制技术研究，wucy@craes.org.cn

中图分类号: X703
计量
- 文章访问数: 107
- HTML全文浏览量: 36
- PDF下载量: 37
- 被引次数: 0
出版历程
- 收稿日期: 2022-08-13
- 修回日期: 2022-10-21

Roasting and Regeneration of Spent Ozone Catalyst for Treatment of Petrochemical Wastewater Biochemical Effluent

QIN Zhikai^{1, 2
,},
FU Liya^{1, 2},
LI Min^{1, 2},
WU Changyong^{1, 2
, ,}

1.
Research Center of Water Pollution Control Technology, Chinese Research Academy of Environmental Sciences, Beijing 100012, China
2.
State Key Laboratory of Environmental Criteria and Risk Assessment, Chinese Research Academy of Environmental Sciences, Beijing 100012, China

Funds: National Key Research and Development Program of China (No.2020YFC1806302-03)

摘要

摘要: 为了解决臭氧催化氧化技术中废旧催化剂处理困难的问题，对用于某石化废水生化出水处理长达5年的废旧臭氧催化剂进行了焙烧再生研究. 通过焙烧能够有效燃烧去除催化剂表面及孔隙中的有机物质，增大催化剂孔径和孔隙率，从而恢复废旧催化剂的部分活性. 单因素试验对催化剂焙烧温度和焙烧时间优化结果表明：①随着焙烧温度从200 ℃提高到500 ℃，再生催化剂用于臭氧催化对石化废水生化出水TOC(总有机碳)的去除效果逐渐提升，500 ℃时TOC去除率可达44.30%，进一步提高焙烧温度去除效果提升不明显. ②焙烧时间为2、3、4和5 h时，再生催化剂处理石化废水效能随焙烧时间增加先升高再降低，4 h时TOC去除效果最好. ③在相同运行条件下，优化焙烧条件(500 ℃、4 h)下得到的再生催化剂对石化废水生化出水的TOC去除率可达新催化剂的77.46%，相较于新催化剂，再生催化剂的颗粒尺寸和平均孔径减小，而比表面积有所增大. ④通过皮尔逊相关性分析，探索了废水中有机物和三维荧光测试结果的相关性，认为荧光区域积分体积可以间接反映石化废水中的有机物含量，也可间接反映臭氧再生催化剂的催化性能. 研究显示，直接焙烧可以作为废旧臭氧催化剂活性再生的一种有效技术手段，具有一定的应用前景.
- 废旧催化剂 /
- 再生 /
- 焙烧 /
- 臭氧 /
- 催化氧化
Abstract: In order to solve the problem of difficult disposal of spent catalysts in ozone catalytic oxidation technology, the roasting and regeneration of spent ozone catalyst used in the biochemical effluent treatment of a petrochemical wastewater for 5 years was studied. The calcination could effectively remove the organic matter on the surface and pore of the catalyst, increase the pore size, increase the specific surface area and porosity of the catalyst, and restore part of the activity of the spent catalyst. The catalyst calcination temperature and calcination time were optimized by single factor experiment. The results show that: (1) With the increase of the roasting temperature from 200 ℃ to 500 ℃, the removal effect of the regenerated catalyst for ozone catalysis on the biochemical effluent of petrochemical wastewater was gradually improved, and the TOC removal rate reached 44.30% at 500 ℃, further increasing the roasting temperature did not improve the TOC removal rate significantly. (2) When the roasting time was 2, 3, 4 and 5 h, the efficiency of the regenerated catalyst to treat petrochemical wastewater increased first and then decreased with the increase of the roasting time, and the TOC removal rate was the highest at 4 h. (3) Under the same operating conditions, the TOC removal rate of the regenerated catalyst obtained under the optimized roasting conditions (500 ℃, 4 h) in the biochemical effluent of petrochemical wastewater could reach 77.46% of that of the new catalyst. Compared with the new catalyst, the particle size and average pore size of the regenerated catalyst were reduced, and the specific surface area was increased. The study also explored the correlation between the organic matter in the wastewater and the results of three-dimensional fluorescence test through Pearson correlation analysis. (4) The analysis showed that the integrated volume of fluorescence area indirectly reflected the content of the organic matter in petrochemical wastewater, and can indirectly reflect the catalytic performance of ozone regeneration catalyst. The study has shown that direct roasting can be used as an effective technical means to regenerate the activity of spent ozone catalysts and has certain application prospects.
- waste catalysts /
- regeneration /
- roast /
- ozone /
- catalytic oxidation

HTML全文

图 1 不同焙烧温度制得再生催化剂对石化废水生化出水处理效果

Figure 1. Effect of regenerated catalyst prepared at different roasting temperatures on biochemical effluent treatment of petrochemical wastewater

下载: 全尺寸图片幻灯片

图 2 原水及不同焙烧温度(4 h)制得再生催化剂处理石化废水出水三维荧光光谱

注：Ⅰ、Ⅱ、Ⅲ、Ⅳ和Ⅴ分别表示类酪氨酸、类色氨酸、类富里酸、类溶解性代谢产物和类腐殖酸. 下同.

Figure 2. Three-dimensional fluorescence spectra of raw water and effluent from different roasting temperatures (4 h) prepared by regenerated catalysts for petrochemical wastewater treatment

下载: 全尺寸图片幻灯片

图 3 不同焙烧温度(4 h)制得再生催化剂处理石化废水进出水荧光强度积分体积及百分比

Figure 3. Integral volume and percentage of fluorescence intensity of influent and effluent of petrochemical wastewater treated with regenerated catalysts prepared at different roasting temperatures (4 h)

下载: 全尺寸图片幻灯片

图 4 不同焙烧时间(500 ℃)制得再生催化剂对石化废水生化出水处理效果

Figure 4. Effects of regenerated catalysts prepared with different roasting times (500 ℃) on the treatment of petrochemical wastewater biochemical effluent

下载: 全尺寸图片幻灯片

图 5 原水及不同焙烧时间(500 ℃)制得再生催化剂处理石化废水出水三维荧光光谱

Figure 5. Three-dimensional fluorescence spectra of raw water and effluent from different roasting times (500 ℃) prepared by regenerated catalysts for petrochemical wastewater treatment

下载: 全尺寸图片幻灯片

图 6 不同焙烧时间(500 ℃)制得再生催化剂处理石化废水进出水荧光强度积分体积及百分比

Figure 6. Integral volume and percentage of fluorescence intensity of influent and effluent of petrochemical wastewater treated with regenerated catalysts prepared at different roasting times (500 ℃)

下载: 全尺寸图片幻灯片

图 7 催化剂焙烧前后的图片及再生催化剂的SEM示意

Figure 7. Pictures before and after the catalyst calcination and SEM of the regenerated catalyst

下载: 全尺寸图片幻灯片

图 8 优化条件再生催化剂(500 ℃、4 h)和新催化剂对石化废水生化出水的处理效果比较

Figure 8. Comparison of the treatment effect of the regenerated catalyst under optimized conditions (500 ℃, 4 h) and the new catalyst on the biochemical effluent of petrochemical wastewater

下载: 全尺寸图片幻灯片

表 1 再生催化剂和新催化剂的比表面积、颗粒大小和平均孔径

Table 1. Surface area and particle size of regenerated and new catalysts

催化剂类型	比表面积/(m²/g)	颗粒尺寸/mm	平均孔径/nm
新催化剂	146.6	2~4	12.79
再生催化剂	185.4	1~3.5	8.55

下载: 导出CSV

表 2 TOC、UV₂₅₄与荧光区域积分体积的线性回归关系(n=28)

Table 2. Linear regression relationship between TOC, UV₂₅₄ and volume integral of different area in 3D-EEMs (n=28)

回归方程	R²	回归方程	R²
C_TOC = 2.449×10⁻⁵Ф_Ⅰ + 4.643	0.322	UV₂₅₄= 1.031×10⁻⁶Ф_Ⅰ − 0.017	0.448
C_TOC = 5.849×10⁻⁶Ф_Ⅱ + 1.051	0.742	UV₂₅₄ = 2.240×10⁻⁷Ф_Ⅱ − 0.115	0.854
C_TOC = 1.090×10⁻⁵Ф_Ⅲ + 7.881	0.848	UV₂₅₄= 4.098×10⁻⁷Ф_Ⅲ − 0.152	0.940
C_TOC = 6.050×10⁻⁶Ф_Ⅳ + 4.693	0.816	UV₂₅₄= 2.229×10⁻⁷Ф_Ⅳ + 0.040	0.870
C_TOC = 5.901×10⁻⁶Ф_Ⅴ + 8.971	0.912	UV₂₅₄ = 2.161×10⁻⁷Ф_Ⅴ + 0.199	0.960

下载: 导出CSV

表 3 TOC去除率、UV₂₅₄降低率与荧光区域积分体积变化量Pearson相关性(n=14)

Table 3. Pearson relationship between the removal rates of TOC, UV₂₅₄ and variations of volume integral of different area in 3D-EEMs (n=14)

项目	Г_TOC	$ {\varGamma }_{{\mathrm{U}\mathrm{V}}_{254}} $	Ф_Ⅰ变化量	Ф_Ⅱ变化量	Ф_Ⅲ变化量	Ф_Ⅳ变化量	Ф_Ⅴ变化量
Г_TOC	1	0.962^**	−0.031	0.139	0.440	0.137	0.374
$ {\varGamma }_{{\mathrm{U}\mathrm{V}}_{254}} $		1	−0.051	0.095	0.348	0.081	0.290
Ф_Ⅰ变化量			1	0.833^**	0.681^**	0.676^**	0.427
Ф_Ⅱ变化量				1	0.876^**	0.873^**	0.719^**
Ф_Ⅲ变化量					1	0.905^**	0.886^**
Ф_Ⅳ变化量						1	0.921^**
Ф_Ⅴ变化量							1
注：**表示在0.01级别(双尾)上显著相关.

下载: 导出CSV
