单井抽出-回渗同步循环地下水水力控制技术研究
Research upon single well pumping-recharge synchronous cyclical groundwater hydraulic control technique
-
摘要: 搭建实验室尺度砂柱孔隙含水层物理模型(直径100 cm,高度100 cm,填土高度70cm)并基于该物理模型构建MODFLOW地下水流数值模型,研究了通过单井抽出-回渗同步循环过程来实现人工对地下水流场和水力梯度的有效控制的可行性及水文地质条件和水动力条件的影响.结果表明:物理装置运行一段时间后,降深曲线不再变化,抽出-回渗达到平衡;基于砂柱含水层不同位置、不同深度实测水位校准后的数值模型的精度较为理想(纳什效率系数为0.88),可以较好的刻画实现水力控制时物理模型中的实际地下水流场;抽出-回渗量的变化对水位降落漏斗的范围几乎无影响,影响半径(28.0-28.5 cm) 几乎不随抽出-回渗量的变化而变化,而抽出-回渗量的变化对水位降落漏斗的深度影响较大,抽出-回渗量越大,降落漏斗的深度越大,当抽出-回渗量分别为1、2.5、5、10 cm3/s时,最大降深分别达到1.76、4.55、9.75、18.65 cm,分别为含水层厚度的2.5%、6.5%、13.9%、26.6%;基于潜水完整井稳定流公式——裘布依公式,实现水力控制时含水层不同位置处水位高低与抽出-回渗量大小(水动力条件)和含水层渗透性强弱(水文地质条件)有关,根据16种抽出-回渗和含水层渗透性的不同情景的数值模拟结果的拟合,发现Q/K 与h2-hw2/lgr-lgrw 之间呈线性关系(h-含水层某处水位, hw-抽水井处水位,r-含水层某处与抽水井井轴距离, rw-抽水井半径),拟合系数R2 = 0.99.实验室尺度砂柱含水层物理模型和地下水流数值模型是论证不同水动力条件和水文地质条件下单井抽出-回渗同步循环地下水水力控制技术可行性的重要手段,可以为该技术在实际场地的应用提供重要参考.Abstract: A laboratory-scale physical model of the sand column pore aquifer (100 cm in diameter, 100 cm in height, and 70 cm in fill height) was built and a numerical model of groundwater flow in MODFLOW was constructed based on the physical model. The feasibility of artificially controlling the groundwater flow field and hydraulic gradient through a single well pump-out-return infiltration synchronous cycle process and the influence of hydrogeological and hydrodynamic conditions were investigated. The results show that after the physical device is operated for a period of time, the water level drop depth curve no longer changes, the pumping-return seepage reaches equilibrium, and the accuracy of the calibrated numerical model based on the measured water level at different locations and depths in the sand column aquifer is satisfactory (the Nash efficiency coefficient is greater than 0.8), which can better portray the actual groundwater flow field in the physical model. The change of pumping-return seepage volume has almost no effect on the range of water level landing funnel, and the radius of influence (28.0-28.5 cm) hardly changes with the change of pumping-return seepage volume, while the change of pumping-return seepage volume has a greater effect on the depth of water level landing funnel, the greater the pumping-return seepage volume, the greater the depth of landing funnel, when the pumping-return seepage volume is 1, 2.5, 5, 10 cm3/s, the maximum depth of landing funnel reaches 1.76, 4.55, 9.75, 4.55, 9.75, 10 cm3/s, respectively. The water level at different locations of the aquifer is related to the magnitude of the withdrawal-return seepage volume and the permeability of the aquifer when hydraulic control is achieved. The linear relationship between Q/K and h2-hw2/lgr-lgrw (h- water level at an aquifer, hw- water level at the pumping well, r- the distance between an aquifer and the pumping well shaft, rw- radius of the pumping well) was determined with the fitting coefficient R2 = 0.99. The physical model of the laboratory-scale sand column aquifer and the numerical model of groundwater flow were used to demonstrate the relationship between different hydrodynamic conditions and The laboratory-scale physical model of sand column aquifer and numerical model of groundwater flow are important tools to demonstrate the feasibility of single-well pumping-infiltration synchronous cycle groundwater control technology under different hydrodynamic and hydrogeological conditions and can provide important references for the application of this technology in practical sites.
